ProChip System

The MYLAPS ProChip Timing System is fast, reliable and easy to use. The system can be used at a wide range of active sports, including cycling, running, triathlon, skating, swimming, biathlon and more.

Sports:    High speed accuracy  ✔  2 – 5000 participants

The ProChip Timing System is fast, reliable and easy to use. The system can be used at a wide range of active sports, including cycling, running, triathlon, skating, swimming, biathlon and more. Our ProChip System is very suitable for professional events: it is very accurate and can determine the closest of finishes.
Get in touch about ProChip

Timing Setup

Timing a race, whether it’s a small race on the local track or a professional cycling race or triathlon, is a challenging task. You only want the best equipment with the highest read-rates and the best accuracy. The MYLAPS ProChip System is the best in the market for the job, check-out the setup and add services to give your participants the best result possible.

The MYLAPS ProChip decoder is the beating heart of the system. It receives passing times from the detection loop and translates this into data the software can work with.

The detection loop is connected to the decoder. This decodes the received signals into the athletes ID and records (lap) times to the millisecond. The maximum distance between the detection loop and the decoder is 100 meter (330ft) which can be covered by a high quality coax cable. The Prochip decoders are available in 2 versions; The standard Prochip decoder (RED) and the Portable Prochip decoder (Yellow)

The Prochip decoder sends this data to the timekeeper’s computer. The decoder has a built-in practice mode that allows automated uploads of practice results to the internet, without the need of a timekeeper.

Portable ProChip decoders are housed in a sturdy Pelican Case. This makes them easy to carry to any event, and fully weatherproof. The decoder weighs around 10kg and when fully charged it will function for over 15 hours: long enough to deal with triathlons.



Attached to the detection loop, it decodes the transponder signal into the runner’s ID at the exact time at which the runner crossed the time line. The table-top decoder needs to be attached to an external power source.

Features

  • Easy system set-up with simple wire antennas
  • Easy to handle, easy to carry
  • Intuitive operation
  • Highly accurate GPS synchronization
  • Connectivity through Ethernet

Detection loops are installed in the track at the start and finish line and intermediate time points. The loops work as the system´s antennas and pick up the ProChips signals.

The detection loop can be installed in basically every type of surface.

  • Asphalt or concrete (not permanent): use industrial quality adhesive tape to affix the loop to the course. Make sure you use high quality tape to secure the tape to the road.
  • Ice: Cut slots of approximately 2 cm (1inch) deep in the ice, embed the loop wires and fill with water. Make sure to do this well in advance of an event, as the water will need some time to freeze.
  • Snow: cut slots in the snow, approximately 20 cm (8 inch) deep. Place the loop wires in the slot and fill them with snow.

ProChips can be used at many different types of sports. They come with ankle strap for use at triathlons, swimming and more.

The ultimate system for high-speed elite sports

All athletes have a ProChip FLEX attached to their ankle/wrist strap or bike in order to identify each participant and to record the exact time at which they pass the start, finish and intermediate time lines. Each ProChip sends out a unique signal to the ProChip system that is embedded in the track.

The ProChip FLEX: used for many different sports

The ProChip Flex can be used for many different types of sports. They come with ankle strap for use at triathlons, swimming and more. When used at cycling events it is recommended to mount the ProChip FLEX on the bicycle’s front fork, as close as possible to the front axle, by using cable ties.

Features

Every MYLAPS ProChip FLEX comes with a subscription for 1, 2 or 5 years. After the initial subscription period, the subscription can be renewed.

  • Timing Resolution: 0.003 sec
  • Density: 4800 chips/minute
  • Housing: Water- and shockproof
  • Numbers available: unlimited

MYLAPS ProChips are highly durable and can even be washed in your washing machine!

Buy your personal ProChip

The ProChip Timer is the newest addition to the ProChip System. Together with the ProChip Communicator it is the fastest manageable timing chip in bulk. Try it now.

Manage and activate your ProChips in bulk

ProChip Timer is a timing solution for timers that have to manage a large number of chips at once. The bulk-activation functionality of the ProChip in combination with the ProChip Communicator makes the process of checking and activating ProChips smooth and effortless. You always know what ProChips are ready for the next event and which ones you need to update.

The ProChip is the proven reliable chip with an upgraded processor. It has best in class read-rates, high speed accuracy and is used at all A level events in the world. Each chip is unique which guarantees athlete identification up to 0.003 seconds.

To use the chip in races you need an active 1, 2 or 5 year subscription that you can activate with the ProChip Communicator in MYLAPS Connect.

The ProChip comes with a practice option for facilities where a ProChip System is installed. In practice mode it is possible to effortlessly use the system with automated online training data.

Why ProChip Timer?

The ProChip Timer is designed to make it easier to manage and update your ProChips in one overview.

Pros of the ProChip Timer:

  • Easy bulk activation & mass subscription renewal
  • Best in class read-rates and high speed accuracy up to 0.003 seconds
  • Wireless management of your battery-powered ProChips
  • Clear overview of ProChips owned, status and subscription wallet via portal.mylaps.com
  • Compatible with the proven ProChip System



More information

MYLAPS Orbits 4 Software is a complete and extremely user-friendly software package that allows you to prepare entry lists, set up races and process, print, publish and upload results to mylaps.com.

The software for high-speed active sports

Orbits 4 Software is used for high-speed active sports, such as ice skating and inline skating. It is a complete and user-friendly software package.It includes easy to use wizards which can assist with quicker start-up and customizing to your preferences.

It takes care of:

  • Event Setup
  • Registration
  • Event timing
  • Results processing
  • Results distribution
  • Championship management
MYLAPS-Orbits-Cycling-Featured

The MYLAPS camera ensures you will have high quality photos and videos under all circumstances. Powered over Ethernet and directly connected to the PhotoVideo Integrator it is the perfect match up. Designed for all weather conditions and sports the MYLAPS camera delivers:

  • 8 MP resolution photos
  • Full HD video recording

The MYLAPS PhotoVideo Integrator is the beating heart of our game changing innovation. Fully integrated with existing MYLAPS timing hardware the PhotoVideo Integrator ensures:

  • Reliable and accurate photos and videos
  • Easy and fast setup
  • Super fast and smart data handling

The platform for active sports results

MYLAPS Sporthive is the practice and event results platform for running, cycling, triathlon, skating, mud and fun runs and all other forms of active sports. Results from ProChip-timed events will be uploaded to MYLAPS Sporthive instead of mylaps.com and other event results will also be integrated on the new platform.

Visit Sporthive
MYLAPS Sporthive
  • Basic system component
  • Full experience
  • Optional component

Transponders

For different sports we have different solutions. Choose the chip that suits your event best, based on the sport, the size of the event and the setting in which the event is held.

ProChip FLEX

All athletes have a ProChip FLEX attached to their ankle/wrist strap or bike in order to identify each participant and to record the exact time at which they pass the start, finish and intermediate time lines. Each ProChip sends out a unique signal to the ProChip system that is embedded in the track.

ProChip Timer

ProChip Timer is a timing solution for timers that have to manage a large number of chips at once. The bulk-activation functionality of the ProChip in combination with the ProChip Communicator makes the process of checking and activating ProChips smooth and effortless.

Sports

ProChip is widely used in cycling. To time a race accurately on high speed you need precise timing with a best in class readrate, that's why major races rely on ProChip. Cyclists want reliable results and a place where they can view these results.

Timing a multisports race is challenging. The chips have to work well in different environments and with different speeds. This is why races use ProChip, because it can be used, in the water, on the bike and during running.

The conditions in which you time your race are not always good and the terrain can be quite remote. So you need a solution that's easy to setup and fit for any condition. ProChip is used in a lot of Snow Sports and during the Olympics.

Services

Live Timing

  1. When to use

  2. Live Tracking
  3. Sports:
  4. Broadcast to followers
MYLAPS Sporthive

Optimize your race experience with real-time results! Get the most out of your race event by broadcasting live race results to your fans and followers. With the new Speedhive Live Timing Web you’re fully equipped for your upcoming races.

Read more.

Customer stories

Giro d'Italia

The Giro d'Italia is the first big tour of the cycling season. With the challenging and divers parcours it's always an exciting race to watch. For timing they relay on ProChip.

IRONMAN Maastricht

The most iconic sports there is, is triathlon, with 3 different disciplines you have to perform your best in all sports. That's why we are so proud to have the IRONMAN timed with ProChip.

Contact us about ProChip



Don’t hesitate to contact us if you want a personal consultation about the best timing system for your situation.
